Application
Hot water circulating for domestic and commercial hot water systems
Cold water circulating for air-conditioning and cooling systems
Features and Construction
In–line pump casing for easy installation
Barrel unions on suction and delivery for easy installation and maintenance
3-speed manual adjustment to suit various applications
Manual bleed on start-up
Low power consumption
Reliable and maintenance-free
Quiet operation
Pump Casing: Bronze DR
Motor Shaft: Ceramic
Impellers: PP Composite
Bearings: Ceramic
Seals: EPDM
Motor IP44
Insulation class F
In-built capacitor and thermal protection
Operating Limits
Clean water without abrasives or suspended solids
Max. Liquid temperature 110°C
Max. Ambient Temperature 40°C
Max. Flow 60 L/min
Max. Operating Pressure 10 Bar
Maxijet Hyjet HCP2060 20mm Hot or Cold Water Circulating Pump Bronze domestic and commercial hot water circulating for air–conditioning and cooling systems.
