Application
Hot water circulating for domestic and commercial hot water systems
Cold water circulating for air-conditioning and cooling systems
Features
In–line pump casing for easy installation
Barrel unions on suction and delivery for easy installation and maintenance
3-speed manual adjustment to suit various applications
Manual bleed on start-up
Low power consumption
Reliable and maintenance-free
Quiet operation
Construction
Pump Casing: Stainless Steel
Motor Shaft: Ceramic
Impellers: PP Composite
Bearings: Ceramic
Seals: EPDM
Motor IP44
Insulation class F
In-built capacitor and thermal protection
Operating Limits
Clean water without abrasives or suspended solids
Max. Liquid temperature 110°C
Max. Ambient Temperature 40°C
Max. Operating Pressure 10 Bar
Flow. 58 L/min
Connections. DN1"
Maxijet Hyjet HPD20-60-150S 20mm Hot or Cold Circulating Water Pump Stainless 3 Speed for domestic and commercial hot water systems. Cold water circulating for air–conditioning and cooling systems.
