Accurate temperature settings are no longer a problem, thanks to the LCD controller. This allows direct accurate continuous flow temperature delivery selection between 20 and 60 °C. With 3i technology for high efficiency and output, the DHB-E LCD provides a reliable and constant supply of hot water.
Ideal Installation Areas. Bathrooms, Apartments, Commercial bathrooms or sinks, Restaurants or Cafes
Electronically controlled
Accurate temperature delivery selection between 20 and 60 °C
Suitable for hard and soft water areas
LCD Controller
Bare wire element is suitable for hard and soft water areas
Rated output (415V) 14.5kW. Rated current (415V) 20.2Amp. Phases 3/PE
Dimensions H 466mm x W 225mm x D 116mm
Made in Germany.
WaterMark Lic No. WMKA00301, AS3498
CALCULATING OUTPUT WATER TEMPERATURE:
Add below temperature rise value to Seasonal Average incoming cold-water temperature to calculate output at a desired flow rate. Typical Basin or Sink Tap Flow Rate is 6 Lpm and a Shower 9 Lpm
DHBE13 LCD AU TEMPERATURE RISE (415 V) Litres Per Minute
6 L/min +34°C. 8 L/min +26°C. 10 L/min +21°C. 12 L/min +17°C. 14 L/min +15°C
Refer Download for Further Information & Water Temperature Output Calculations and Flow rates
7 Year full parts and labour domestic warranty*
*Conditions apply - refer Stiebel Eltron warranty policy for full details.
Must be installed by a qualified licensed person in accordance with manufacturer’s instructions and all relevant plumbing and electrical regulations.
Stiebel Eltron DHB-E 13 LCD AU Electric Instantaneous Water Heater 60°C 14.5kW 3 Phase with 3i technology for high efficiency and output, the DHB-E LCD provides a reliable and constant supply of hot water.
